IPEVO VZ-X ULTRA

Спецификации на уеб камера IPEVO VZ-X ULTRA 13MPx

Ipevo DOK VZ-X Ultra, 4712098411830, 5-929-2-08-00

IPEVO VZ-X ULTRA 13MP WIRELESS, HDMI & USB DOCUMENT CAMERA

Stunning Visuals,
Delivered Wirelessly

13MP Clarity. Zero Setup. Teach Wirelessly

The IPEVO Wireless Classroom Plus Bundle (VZ-X ULTRA + Wireless USB/HDMI™ Receiver) delivers 13MP image clarity and effortless, cable-free streaming to any USB or HDMI display. With instant plug-and-play pairing and a dedicated wireless connection that doesn’t rely on school Wi-Fi, teachers can set up in seconds, move freely, and teach with smooth, low-latency performance—any screen, anywhere.

• 4K Wireless Streaming
• Zero Network
• Impact
• Brighter onboard LED
• Sony Image Sensor
• Plug & Play
• AI Noise Reduction

From Device to Display in Seconds

The IPEVO Wireless Classroom Plus Bundle (VZ-X ULTRA + Wireless USB/HDMI™ Receiver) redefines classroom flexibility with stunning image clarity and seamless wireless performance.

With Wi-Fi, HDMI, and USB connectivity, plus the included 4K wireless receiver, projecting to any screen is fast and effortless—no cables, no lag, no limits. Set up in seconds, move freely around the classroom, and teach with uncompromising clarity wherever learning happens.

• Wireless HDMI
• Wireless USB & HDMI Receiver
• Wi-Fi Access Point
• Cable HDMI & USB

Wirelessly Cast to an HDMI Monitor or TV Without a PC

In the version that includes the 4K wireless display receiver, the VZ-X ULTRA connects seamlessly for wireless projection to any HDMI TV or monitor—no computer required.It pairs automatically with the included receiver, ensuring a quick and effortless setup.

Note: 4K wireless display receiver included.

Stay Connected to the Internet While Using VZ-X ULTRA

The IPEVO Wireless USB/HDMI™ Receiver is the ideal companion for IPEVO Wi-Fi document cameras like the VZ-X ULTRA. With automatic pairing and Zero-Driver Setup, it delivers true plug-and-play simplicity. Powered by Wi-Fi 5 for stable performance, it supports UHD 4K30 output via HDMI and USB.

Note: Wireless USB/HDMI™ Receiver included.

Connect Directly from Your Laptop or Tablet

The camera features a built-in Wi-Fi access point, allowing laptops and tablets to connect directly without the need for an external network or router. Simply search for the camera’s Wi-Fi signal on your device, connect, and start streaming or controlling the camera—anytime, anywhere.

Stream Images via HDMI or USB Connection to Your Display or Laptop

Stream real-time images to your TV, projector, or monitor via HDMI. You can also connect the VZ-X ULTRA to your laptop or PC via USB for both power and data transfer.

Note: HDMI doesn’t supply power to the VZ-X ULTRA. Ensure sufficient battery or connect to a 5V/2A USB power adapter, or a powered USB port on your TV, projector, or computer.

Specifications

General

• Product name: IPEVO VZ-X ULTRA 13MP WIRELESS, HDMI & USB DOCUMENT CAMERA
• Model: CDVH-06IP
• Part number
• 5-929-2-08-00（IPEVO VZ-X ULTRA + 4K Wireless Display Receiver）
• 5-929-2-08-01（IPEVO VZ-X ULTRA + Wi-Fi USB Adapter）
• Flash: 256MB
• LED illuminator: White LED x 1, 140lux @ 30cm

Camera

• Sensor: 1/3.06" CMOS
• Max resolution: 3840 x 2160
• Lens type: Auto Focus
• Focal length: 3.46 mm
• Aperture: 2.2
• FOV: DFOV: 79.3
• Max Shooting Area
• 20.07 x 11.8 (510 x 300mm) [16:9]
• 16.1 x 11.8 (410 x 300mm) [4:3]
• Shutter time: 1/7.5 ~ 1/30000 sec
• WDR: N/A
• Zoom: 1x ~ 4x (Digital) 1x ~ 20x (via Visualizer)

Video

• Video compression: MJPG YUV H.264 (WiFi mode)
• Max frame rate
• 4096 x 3072 @15 fps
• 3264 x 2448 @30fps
• 3840 x 2160 @30fps
• 1920 x 1080 @60fps (Default)
• 1920 x 1080 @30fps

Microphone

• Type: Omni-directional microphone
• Audio compression: PCM
• Pick up range: 30 ~ 70cm
• SNR: 60 dB
• Frequency range: 48K 1ch-16bit PCM

Battery

• Battery Capacity: 9.9 Ah
• Battery Life: 9~12 hours

Connectivity

• USB-C (UVC/UVA)
• HDMI
• Wi-Fi (2.4G and 5G dual band)

Power

• Power input: DC 5V / 0.9A (USB - C connector)
• Power consumption: 5V/0.6A (max without charger)

Compatabilty

• - Windows : Win 8 and abouve / Standard UVC
• - MAC: macOS 10.13 and above
• - Android: Ver.11 and above

Environmental requirements

• Operating temperature: 32°F to 104°F (0°C to 40°C)
• Storage temperature: 14°F to 122°F (-10°C to 50°C)
• Humidity: 95% @ 25°C

Size and weight

• Dimension: D x W x H (when folded) 4.57 x 4.25 x 12.68 (11.6 x 10.8 x 32.2cm)
• Weight: 2.58 lbs (1172g)

Package Contents

• IPEVO VZ-X ULTRA
• (+ 4K Wireless Display Receiver) Part No.: 5-929-2-08-00
• -IPEVO VZ-X ULTRA
• -USB-A to USB-C Cable (4.92 ft / 1.5 m)
• - 4K Wireless Display Receiver
• -Quick Start Guide
