Asus ProArt PA24US

Спецификации на Asus ProArt PA24US 23.6’’ 3840x2160 5ms

ASUS ProArt PA24US - LED-Monitor - 4K - 61.2 cm (23.6") - HDR, 4711387267080, 90LM097A-B01370

ASUS ProArt Display PA24US Professional Monitor – 24-inch (23.6-inch viewable), IPS, 4K UHD (3840 x 2160), Built-in Motorized Colorimeter, Self / Auto Calibration, HDR-10, HLG, 99% Adobe RGB, 95% DCI-P3, ΔE < 1, 12G-SDI, USB-C PD 80W, VESA DisplayHDR 600, Hardware Calibration, Calman Ready, ColourSpace Integration, Ergonomic Stand, Green Sustainability

• 23.6-inch 4K (3840 x 2160) high-quality panel with 600 nits peak brightness, HDR-10, HLG support
• Built-in colorimeter supports Self / Auto calibration, as well as Calman and Light Illusion ColourSpace CMS professional hardware calibration software
• True 10-bit color depth, 99% Adobe RGB, 95% DCI-P3 wide color gamut
• 12G-SDI supports 4K@60Hz real-time playback without any compression
• Extensive connectivity including 12G-SDI input, full function USB-C with 80W Power Delivery, DisplayPort, HDMI, USB hub for the most flexibility
• Ergonomic design with tilt, swivel, pivot and height adjustments for a comfortable viewing experience
• Green Sustainability: paper packaging and energy-efficient environmental standards

ProArt Display PA24US
On-set SDI Monitor

ProArt Display PA24US is 23.6-inch 4K HDR monitor offers 187 high PPI IPS panel with 99% Adobe RGB and 95% DCI-P3 coverage to deliver highly accurate colors that bring out the finest details in your creations. 12G-SDI input can receive video signals up to 4K@60Hz and up to quad-view at same time.

A built-in motorized flip colorimeter for auto / self calibration to ensure professional-grade color accuracy. 600 nits peak brightness with multiple HDR format support provides creators with the ideal platform for working HDR content.

• 4K HDR - 23.6-inch, 3840 x 2160
• 187: High PPI
• IPS 178° Wide-view
• 10-bit Color Depth
• 99% Adobe RGB
• 95% DCI-P3
• 600 nits Peak Brightness
• Self / Auto Calibration: Built-in Motorized Flip Colorimeter
• HDR: HDR-10, HLG
• 12G-SDI Input
• Seamless Calibration
• Ergonomic Stand: Swivel, Tilt, Pivot, Height Adjustment
• Comprehensive Connectivity: 12G-SDI, Full-function USB-C®, HDMI®, DisplayPort™ and USB Hub

Empowering Content Creators

Digital Imaging Technician (DIT)

Needs a hi-quality SDI monitor for on-set quick color grading and managing production workflow. It can provide precise and true color reproduction and details from camera and present to director/customers.

Colorists

12G-SDI input connection let creators who using SDI PCIe capture cards or capture boxes can be directly connect to the PA24US via SDI instead of HDMI, delivers 4K high quality uncompressed videos to preview precise image performance.

Filmmakers & Video Editors

An ultra-high-resolution with wide-color-gamut monitor performance is a must-have tool for 4K HDR video production. Factory pre-calibration ensures industry-leading color fidelity, and a wide color gamut and Delta E < 1 color difference ensures outstanding color accuracy.

• Impeccable 4K HDR Imagery On-set
• Uncompressed 4K Video
• IPS 178° Wide View Angle

A brighter, Lifelike Viewing Experience

Uncompressed 4K Video

23.6-inch with 4K UHD (3840 x 2160) panel delivers four times the pixel density and three times more onscreen space than similarly sized FHD displays, resulting in sharper visuals with greater levels of detail.

ProArt Display PA24US features 12G-SDI connection, allows receiving and transmitting uncompressed up to 4K@60Hz video footage directly from camera devices with ultra-low latency.

Lifelike Views With 178° Wide View Angle

Frameless IPS panel provides 178° viewing angles, both horizontally and vertically, so you can enjoy its beautiful visuals from almost any direction.

High Dynamic Range

ProArt Display PA24US features up to 600 nits of brightness, also passed VESA DisplayHDR 600 certification. Multiple HDR format supports HDR-10 / HLG high dynamic range technology for brighter whites and darker blacks, resulting in a rich and lifelike viewing experience.

Intuitive and Intelligent Calibration

ProArt Calibration

ASUS ProArt Calibration technology saves all color parameter profiles on the ProArt monitor’s internal scaler IC chip, instead of on the PC. The monitor can be calibrated and the look-up table subsequently rewritten, allowing users to connect it to devices with different operating systems or applications without needing to adjust settings.

ProArt Color Center

ProArt Color Center offers remote group control and calibration tools, allowing you to handle these vital tasks from a centralized location. You’ll be able to remote control & group calibration, scheduled calibration and customized color parameters to maintain professional-level accuracy and consistency all the time.

Seamless Calibration

ProArt Displays are compatible with most major calibrators, including those from X-Rite, Datacolor and Klein. They also work seamlessly with Calman and Light Illusion ColourSpace CMS professional hardware calibration software.

Self Calibration

ProArt Displays now boasts an innovative self-calibration feature for the embedded colorimeter. The self-calibration is a standalone solution without any software and compatible with any operating system.

You can directly complete the color calibration and scheduled color calibration functions through the OSD operation of ProArt Display. With this flexibility, you can achieve color consistency anytime and anywhere.

Display

• Panel Size (inch) : 23.6
• Aspect Ratio : 16:9
• Display Viewing Area (H x V) : 522.43 x 293.87 mm
• Display Surface : Non-Glare
• Backlight Type : LED
• Panel Type : IPS
• Viewing Angle (CR≧10, H/V) : 178°/ 178°
• Pixel Pitch : 0.135mm
• Resolution : 3840x2160
• Color Space (sRGB) : 100%
• Color Space (Adobe RGB) : 99%
• Color Space (DCI-P3) : 95%
• Brightness (HDR, Peak) : 600 cd/㎡
• Brightness (Typ.) : 350cd/㎡
• Contrast Ratio (HDR, Max) : 1,000,000:1
• Contrast Ratio (Typ.) : 1000:1
• Display Colors : 1073.7M (10 bit)
• Response Time : 5ms(GTG)
• Refresh Rate (Max) : 60Hz
• HDR (High Dynamic Range) Support : HDR10
• HDR (High Dynamic Range) Support : HLG
• Flicker-free : Yes
• LCD ZBD Warranty : Yes(3 yr)

Video Feature

• Trace Free Technology : Yes
• ProArt Preset : Standard
• ProArt Preset : sRGB
• ProArt Preset : Adobe RGB
• ProArt Preset : DCI-P3
• ProArt Preset : Rec. 2020
• ProArt Preset : DICOM
• ProArt Preset : Rec. 709
• ProArt Preset : HDR_PQ DCI
• ProArt Preset : HDR_PQ Rec2020
• ProArt Preset : HDR_HLG
• ProArt Preset : HDR_HLG BT2100
• ProArt Preset : HDR_HLG DCI
• ProArt Preset : User mode1
• ProArt Preset : User mode2
• ProArt Preset : User mode3
• Color Temp. Selection : Yes(5 modes)
• Color Adjustment : 6-axis adjustment(R,G,B,C,M,Y)
• Gamma Adjustment : Yes (Support Gamma 1.8/2.0/2.2/2.4/2.6 )
• Color Accuracy : △E< 1
• ASUS ProArt Hardware Calibration : Yes
• ProArt Palette : Yes
• QuickFit Plus : Yes
• PIP / PBP Technology : Yes
• HDCP : Yes, 2.2
• VRR Technology : Yes (Adaptive-Sync)
• Motion Sync : Yes
• HDR Preview : Yes
• Low Blue Light : Yes
• Multiple HDR Mode : Yes

Audio Feature

• Speaker : Yes(2Wx2)

I/O Ports

• 12G-SDI x 1
• USB-C x 1 (DP Alt Mode)
• DisplayPort 1.4 x 1
• HDMI(v2.0) x 2
• USB Hub : 2x USB 3.2 Gen 1 Type-A
• Earphone Jack : Yes
• USB-C Power Delivery : 80W

Signal Frequency

• Digital Signal Frequency : 15~135 KHz (H) / 48~60 Hz (V)

Power Consumption

• Power Consumption : <24.1W
• Power Saving Mode : <0.5W
• Power Off Mode : 0W (hard switch)
• Voltage : 100-240V, 50/60Hz

Mechanical Design

• Tilt : Yes (+21° ~ -3°)
• Swivel : Yes (+30° ~ -30°)
• Pivot : Yes (+90° ~ -90°)
• Height Adjustment : 0~130mm
• Embedded Colorimeter : Yes (Support Self-Calibration)
• Ambient Light Sensor : Yes
• VESA Wall Mounting : 100x100mm
• Kensington Lock : Yes

Dimensions (Esti.)

• Phys. Dimension (W x H x D) : 54.9 x 52.1 x 19.0 cm (21.61" x 20.51" x 7.48")
• Phys. Dimension without Stand (W x H x D) : 54.9 x 34.6 x 6.3 cm (21.61" x 13.62" x 2.48")
• Box Dimension (W x H x D) : 76.1 x 15.2 x 47.9 cm (29.96" x 5.98" x 18.86")

Weight (Esti.)

• Net Weight : 6.00 kg (13.23 lbs)
• Net Weight without Stand : 4.30 kg (9.48 lbs)
• Gross Weight : 9.70 kg (21.38 lbs)

Accessories (vary by regions)

• Color pre-calibration report
• DisplayPort cable
• HDMI cable
• Power cord
• Quick release stand
• Quick start guide
• USB-C cable
• Warranty Card
• Welcome Card

Certificate

• TÜV Flicker-free
• TÜV Low Blue Light
• VESA DisplayHDR 600
• Calman Ready
