Philips Videowall 65BDL6005X

Спецификации на Philips Videowall 65BDL6005X 65’’ 3840x2160 8 ms

Philips Videowall Display 65BDL6005X - 164 cm (65") - 3840 x 2160 4K UHD, 65BDL6005X/00

Signage Solutions Video Wall Display 65BDL6005X/00: Get the bigger picture

Ensure every detail is under control. The Philips X-Line Videowall display is designed for 24/7 operation and can be customised to fit all your content needs. View content from multiple sources in real-time with enhanced picture quality

Get the bigger picture - Monitor, manage and control

• 65"
• Direct LED Backlight
• Ultra HD
• 500cd/m²

Operate, monitor and maintain with CMND & Control

Run your display network over a local (LAN) connection.

CMND & Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.

FailOver ensures content is always playing

From waiting room to meeting room, never show a blank screen.

FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs ensuring content keeps playing even if the primary source goes down.

Simply set a list of alternate inputs to be sure your business is always on.

OPS slot allows for PC embedding without cabling

Integrate a full-power PC or Android-powered CRD50 module directly into your Philips Professional Display.

The OPS slot contains all the connections you need to run your slot-in solution, including a power supply.

 Technical Specifications

Picture/Display

• Diagonal screen size (metric): 164  cm
• Diagonal screen size (inch): 64.5  inch
• Panel resolution: 3840 x 2160
• Optimum resolution: 3840 x 2160 @ 60 Hz
• Brightness: 500  cd/m²
• Dynamic contrast ratio: 500,000:1
• Response time (typical): 8  ms
• Aspect ratio: 16:9
• Viewing angle (horizontal): 178  degree
• Viewing angle (vertical): 178  degree
• Pixel pitch: 0.372 x 0.372 mm
• Display colors: 1.07 B
• Contrast ratio (typical): 1300:1
• Haze: 25 %

Supported Display Resolution

• Computer formats; 720 x 400, 70Hz; 800 x 600, 60, 75Hz; 1024 x 768, 60, 75Hz; 1280 x 768, 60Hz; 1280 x 800, 60Hz; 1280 x 960, 60Hz; 1280 x 1024, 60Hz; 1360 x 768, 60Hz; 1366 x 768, 60Hz; 1600 x 1200, 60Hz; 1920 x 1080, 60Hz; 3840 x 2160, 60Hz
• Video formats; 720p, 50, 60Hz; 1080i, 25, 30Hz; 1080p, 50, 60Hz; 3840 x 2160, 60Hz; 2160P 50, 60Hz ((HDMI/OPS/DP)

Connectivity

• Video input; Display Port1.2 (x1); DVI-D (x1); HDMI 2.0 (x2); VGA (Analog D-Sub) (x1)
• Audio input: 3.5 mm mini jack (x1)
• Video output: DisplayPort 1.2 (x1)
• Audio output: 3.5 mm Mini Jack (x1)
• External control; IR (in) 3.5 mm jack; IR (in/out) RJ45; LAN RJ45 (x2); RS232 (in/out) RJ45
• Other connections; OPS; USB 2.0 (x1)

Convenience

• Placement; Landscape (24/7); Portrait (24/7)
• Tiled Matrix: Up to 10 x 10
• Signal loop through; DisplayPort; IR and RS232 via RJ45; LAN
• Ease of installation; Carrying Handles; Smart Insert
• Energy saving functions: Smart Power
• Network controllable: LAN (RJ45)
• Screen saving functions: Pixel Shift, Low Bright

Operating conditions

• Temperature range (operation): 0 ~ 40  °C
• Temperature range (storage): -20 ~ 60  °C
• Altitude: 0 ~ 3000 m
• MTBF: 50,000  hour(s)
• Humidity range (operation)[RH]: 20 - 80% (without condensation)
• Humidity range (storage) [RH]: 5 - 95% (without condensation)

Power

• Consumption (Typical): 210  W
• Consumption (Max): 400 W
• Standby power consumption: 0.5 W
• Consumption (On mode): 150 W
• Energy Label Class: G

Sound

• Built-in speakers: 2 x 10W (RMS)

Accessories

• Included Accessories; AC Switch Cover; Edge Alignment Kit; Gap pad x3; IR sensor cable (1.8 m) (x1); Quick start guide (x1); Remote control & AAA batteries; RJ45 / RS232 converter; Wire Clamper (x3); Power cord; DP cable (x1); RJ45 cable (x1)

Miscellaneous

• On-Screen Display Languages; Arabic; English; French; German; Italian; Japanese; Polish; Russian; Spanish; Simplified Chinese; Turkish; Traditional Chinese
• Regulatory approvals; CE; FCC, Class A; RoHS; CB; ETL

Dimensions

• Set Width: 1432.6  mm
• Set Height: 807.6  mm
• Set Depth: 88.8 mm(D@WallMount)/91.7 mm(D@Handle)  mm
• Set Width (inch): 56.40  inch
• Set Height (inch): 31.80  inch
• Set Depth (inch): 3.50 (D@WallMount)/3.61 (D@Handle)  inch
• Bezel width: 2.3 mm + 1.2 mm
• Wall Mount: 400mm x 400mm, M6
• Product weight: 29.2  kg
